d&b D20 Amplifier for Sale | 4-Channel Professional DSP Amplification

The d&b D20 amplifier for sale combines four Class-D amplifier channels with d&b loudspeaker management, extensive DSP and networked system control in a compact 2U rackmount platform. Developed for professional mobile and installed applications, the D20 is particularly useful for rental companies, theatres, corporate AV providers and venues that need one amplifier to handle power, processing, monitoring and control for compatible d&b loudspeaker systems.

Rather than treating amplification and loudspeaker processing as separate tasks, the D20 integrates them into one platform. As a result, technicians can select supported loudspeaker configurations, apply EQ and delay, compensate for loudspeaker cable effects with LoadMatch and supervise the amplifier through compatible d&b remote-control environments.

Four Channels in Only 2U

One of the D20’s practical strengths is channel density.

The amplifier provides four independent channels while occupying only two rack units. Therefore, professional users can build relatively compact amplifier racks without giving up independent control of multiple loudspeaker circuits.

The supplied power figures include:

• Up to 4 × 1600 W into 4 Ω under specified signal conditions
• 4 × 1000 W into 4 Ω under alternative crest-factor conditions
• Up to 4 × 800 W into 8 Ω
• Four independently processed amplifier channels

Actual available output depends on load, signal characteristics, mains conditions and the selected loudspeaker configuration.

D20 Technical Overview

*Power ratings depend on the applicable crest factor and operating conditions.

Integrated d&b Loudspeaker Processing

The D20 is not simply a generic four-channel amplifier.

Its DSP contains dedicated configurations for supported d&b loudspeakers. Once technicians select the correct speaker setup, the amplifier applies the relevant processing and protection parameters.

This system-based approach is particularly useful for professional operators already working within the d&b ecosystem.

Moreover, it reduces dependence on separate external loudspeaker processors for many conventional system configurations.

Extensive EQ for System Tuning

Professional venues rarely have identical acoustic characteristics. Consequently, system technicians need sufficient processing flexibility to adapt a PA to different environments.

The D20 provides extensive equalization facilities on each channel, including parametric filtering and additional filter types.

This can help engineers address system-tuning requirements while maintaining the underlying manufacturer loudspeaker configuration.

Nevertheless, DSP should complement good system design rather than compensate for incorrect loudspeaker placement or coverage.

Up to 10 Seconds of Delay

The available 10-second delay range gives the D20 considerable flexibility beyond simple cabinet alignment.

In a distributed professional system, technicians may need to align loudspeakers positioned significant distances from the main PA.

Likewise, complex installations can require different timing relationships between individual coverage zones.

The D20 allows these adjustments to take place within the amplifier itself, reducing the need for additional processing hardware in many applications.

LoadMatch for Long Loudspeaker Cables

A notable feature of the D20 is d&b LoadMatch.

Long loudspeaker cables introduce electrical resistance, which can influence system performance. LoadMatch provides cable compensation for compatible d&b systems, helping account for these effects.

This becomes especially valuable in large venues where amplifier racks cannot always sit close to the loudspeakers.

Therefore, LoadMatch can benefit touring systems, theatres and permanent installations with longer cable runs.

Analog and AES3 Digital Inputs

The D20 supports professional analog and digital signal workflows.

Analog XLR connectivity accommodates conventional professional audio sources, while AES3 digital inputs allow the amplifier to integrate into suitable digital signal chains.

This gives system designers greater freedom when planning an amplifier rack.

Additionally, digital configurations can reduce unnecessary conversion stages when the upstream system already provides AES3 audio.

Touchscreen Control at the Rack

A 3.5-inch color TFT touchscreen provides local access to amplifier settings and status information.

The accompanying rotary encoder gives technicians another direct method for navigating menus and making adjustments.

From the front panel, operators can access relevant configuration and monitoring information without connecting an external computer for every change.

That can be particularly useful during equipment preparation, troubleshooting and smaller productions.

Networked Control for Larger Systems

For larger productions, technicians may need to manage many amplifiers simultaneously.

The D20 supports networked operation within compatible d&b remote environments. Therefore, amplifier settings and system status can be supervised from a central control position instead of requiring physical access to every rack.

This becomes increasingly useful as system size grows.

A touring production, for example, may have amplifier racks in several locations around a venue. Centralized monitoring can significantly simplify system management.

d&b D20 Amplifier for Sale for Touring Companies

For rental and touring businesses looking for a d&b D20 amplifier for sale, the combination of four channels and a 2U chassis is particularly attractive.

Less rack space can mean more efficient truck packing, easier handling and more amplifier channels within a given rack size.

In addition, integrated DSP reduces the amount of separate processing hardware required for compatible systems.

Potential applications include:

• Professional PA rental
• Concert touring
• Theatre systems
• Corporate AV production
• Live music venues
• Monitor systems
• Festivals
• Permanent installations
• Distributed sound systems
• Existing d&b amplifier inventories

Professional Power Management and Protection

Touring equipment must deal with changing electrical environments and demanding operating conditions.

The D20 uses a switch-mode power supply with power-factor correction and incorporates protection systems for conditions such as excessive temperature, output faults and inappropriate electrical loads.

Variable-speed cooling also helps manage internal temperature during operation.

These systems are important because professional amplifiers may run for extended periods under demanding conditions.

D20 Compared with D80

Buyers considering this generation of d&b amplification often encounter both D20 and D80.

Both provide four amplifier channels, DSP, touchscreen operation, LoadMatch and network-control capabilities. However, the D80 was positioned for applications requiring greater maximum output capability.

Therefore, choosing between them should not simply come down to selecting the larger amplifier.

The better approach is to identify the loudspeaker system first and then check d&b’s approved amplifier configurations for those cabinets.

For many compatible systems that do not require the D80’s higher output capability, the D20 can provide an efficient professional solution.

Compact and Manageable for Rental Racks

At approximately 10.8 kg, the D20 is considerably lighter than many older professional amplifier platforms.

Its 2U format also means several units can fit into a relatively compact touring rack.

For example, multiple D20 amplifiers can provide a significant number of independently processed channels while keeping overall rack dimensions manageable.

This can benefit rental businesses that regularly move amplifier systems between productions.

Expanding an Existing d&b Inventory

A d&b D20 amplifier for sale can also make sense for companies that already operate compatible D20-based systems.

Additional units may serve as:

• Expansion amplifiers
• Backup inventory
• Additional touring racks
• Installation replacements
• Rental-fleet additions
• Amplification for newly acquired compatible d&b cabinets

Keeping the same amplifier platform across an inventory can also simplify staff training and system preparation.

Compatibility Comes Before Wattage

Professional buyers should avoid choosing a D20 solely because its output figures appear suitable for a particular loudspeaker.

d&b designs its loudspeakers and amplifiers as integrated systems. Therefore, the specific loudspeaker configuration available within the amplifier matters.

Before purchasing, verify that the intended speaker model has an approved D20 setup.

This is especially important when working with previous-generation d&b loudspeakers.

Ordering a d&b D20 Amplifier for Sale in Europe

Euro Electronic Space offers the d&b D20 amplifier for sale in Europe for professional audio customers requiring compatible amplification for touring, rental and installed systems.

Delivery can be arranged to supported European destinations, including Germany, the Netherlands, France and Italy.

Customers purchasing several D20 units can also enquire about consolidated freight. Likewise, amplifiers may be combined with compatible professional audio equipment when available.

Frequently Asked Questions

How many channels does the d&b D20 have?

The D20 provides four independently processed amplifier channels.

Does the D20 have built-in DSP?

Yes. DSP and supported d&b loudspeaker configurations are integrated directly into the amplifier.

Does it support digital audio?

Yes. The D20 supports AES3 digital audio alongside professional analog connectivity.

What is LoadMatch?

LoadMatch is d&b’s cable-compensation technology. It helps compensate for electrical effects introduced by longer loudspeaker cable runs in compatible configurations.

How much delay does the D20 provide?

Up to approximately 10 seconds per channel.

Can the amplifier be controlled remotely?

Yes. The D20 supports networked operation within compatible d&b remote-control environments.

How large is a D20?

It uses a 2U 19-inch rackmount chassis and weighs approximately 10.8 kg.

Should I choose a D20 or D80?

That depends primarily on the d&b loudspeakers being driven and their required amplifier configuration. D80 provides greater maximum output capability for demanding applications, while D20 can be an efficient choice for many supported systems.
